Moons
MOONS' model SRAC8
Power Supply:80-265VAC, Output Current(Peak):0.4-8.0A, Step Resolutions(1.8°Stepper): Full Step, 2x, 4x, 5x, 8x, 10x, 16x, 20x, 25x, 32x, 40x, 50x, 64x, 100x, 125x, 128x Microstepping, Step Pulse Frequency:2MHz Max, Selectable Damping Modes For Smooth Motion ● Advanced Current Control ● Torque Ripple Smoothing ● Anti-Resonance ● Microstep Emulation
Specification
| Parameter | Unit | Value |
|---|---|---|
| phase | 2 | |
| Supply Voltage | 80-265 VAC | |
| Control Modes | Pulse Mode | |
| Output Current | A | 0.4-8 |
| Digital Inputs | 3 | |
| Digital Outputs | 1 | |
| Encoder Feedback | NO | |
| Operating Temp. | ℃ | 0-40℃ |
| Approvals | CE,RoHS | |
| IP Rating | IP20 | |
| Weight | kg | 1.45 |
Product Models
| # | Image | Model Name | Detail |
|---|
Enquire About : Moons MOONS' model SRAC8
